XD80_AL Entrance Door

The XD80_AL stands as the flagship model among CIVRO’s entrance door offerings, exemplifying the pinnacle of design and manufacturing excellence.

Description

A flagship entryway solution with security and functionality

The XD80_AL stands as the flagship model among CIVRO’s entrance door offerings, exemplifying the pinnacle of design and manufacturing excellence.

This door system satisfies the stringent security requirements for entrance doors, meeting the RC3 burglary resistance level. It incorporates a European customised automatic multi-point locking system, featuring an automatically retracting hook bolt, an enhanced anti-burst main lock mechanism, and a magnet automatic locking mechanism. Additionally, an optional motorised locking configuration includes a modular electric lock drive unit.

The system also offers a variety of cutting-edge locking options, such as facial recognition, finger scan, remote control, touch activation, and SmartTouch (keyless) entry. These features provide versatility and convenience for various use cases, while compatibility with mainstream smart home systems enhances its overall functionality.

Furthermore, the XD80_AL includes custom European-made concealed hinges, ensuring the door maintains a flush and seamless appearance. The door is available in multiple configurations, including single-leaf, double-leaf, and asymmetrical double-leaf options, with both inward and outward opening capabilities, catering to a wide range of architectural requirements.

Constructed from sturdy aluminum panels, the XD80_AL door system epitomizes both strength and minimalist elegance. It offers lasting durability and a sleek design that seamlessly complements modern architectural styles.

Details

U-value (W/(㎡·K)) Sound Reduction (dB) Water Tightness (Pa) Burglar Resistance
1.4 37 700 RC3

Overview

Specification XD80IN_AL Entrance Door XD80OU_AL Entrance Door
Design
Opening Inwards opening Outwards opening
Opening type Single, double, unequal double leaf Single, double, unequal double leaf
Basic depth (mm) 80 80
Vent frame depth (mm) 80 80
Face width of frame, low threshold (mm) 19.4 16
Face width of vent frame, low threshold (mm) No No
Face width of frame, high threshold (mm) 80 53.6
Face width of vent frame, high threshold (mm) No No
Threshold height (mm) Low threshold: 19
High threshold: 80
Low threshold: 11
High threshold: 80
Barrel hinge Yes Yes
Concealed hinge (selective) Yes Yes
T profile No No
Meeting stile No No
Motorised locking module Yes Yes
Sintered stone (selective) Yes Yes
Surface finish Powder coating Powder coating
Fixed lights Yes Yes
Leaf Data
Min.-max. leaf height (mm) 2000–3000 2000–3000
Min.-max. leaf width (mm) 550–1200 550–1200
Max. leaf weight (kg) 250 250
Panel thickness (mm) 80 (3+74+3) 80 (3+74+3)
Implementation Scenario
Façade insert unit Yes Yes
Conservatory insert unit Yes Yes
Parameters
U values in W/(㎡·K) 1.4 1.4
Sound reduction (dB) 37 37
Air permeability (m³/(m·h)) 0.5 0.5
Water tightness (Pa) 300 700
Wind load resistance (kPa) ≤5 ≤5
Burglar resistance RC3 RC3

Planning Highlight

RC3 certified with a plethora of unlocking mechanisms, including advanced biometric(facial recognition(mask mode available), finger scan), remote and SmartTouch (keyless) unlocking options

Available in several layouts of handles and leaf enclosing materials(aluminium sheet, sintered stone) to complement any entrance scenario

In terms of leaf enclosing materials, options include double-sided aluminium sheet or sintered stone cladding, as well as designs featuring one side with aluminium and the other with sintered stone

Doors are available in single, double, or unequal double leaf configurations, designed for both inward and outward opening

Customised European concealed hinges can be chosen to ensure a flush and unobtrusive appearance

Choose from a low threshold at 19mm or a high threshold at 80mm, enhancing accessibility

Compatible with various additions such as fanlights, and side or operable configurations in line with the CIVRO XW window series

Compatible with the window series CIVRO XW80

Important Note

All product catalogs and planning data such as product parameters and performances, detailed drawings, attachment to building structure drawings and DWG files, which you obtain from our website, digital centre, franchisers or other channels and which you can save to your computer, are examples which are intended to help you plan and design your project. These contents must be checked for its suitability in the relevant structural scenario. The technical and legal regulations, the site conditions, and the design and structural requirements, must be assessed and planned independently by the developer and observed by the company contracted to do the work. Data or descriptions in these documents may be modified or amended due to technique improvement or design optimisation. PLEASE BE AWARE OF NECESSITY OF PRE-CHECK TO AVOID ANY MISUNDERSTANDING OR PLANNING LOSE.
